Magnum Soldering Products

Soldering Station 2004

The Soldering Station 2004 gives total temperature control with a digital read-out. It comes standard with the Soldering Iron 1002.

Stepless temperature selection between 150°C & 450°C (302°F & 842°F)
Thermocouple sensing to maintain tip temperature within ± 5°C of selected temperature.
Electronic proportional control varies the heating period as required to maintain set temperature.
Continuous 3 digit LED temperature display with 1°C resolution.
Heating pulse indicator.
Units earthed with potential balance socket.
Triac switching at zero-crossover point.
Robust ABS cabinet.
Illuminated rocker switch.
Safety-spring holder.
Cleaning sponge.
Spare tip storage.
Potential balance socket.

Input	220/240v 50/60Hz external 500mA fuse
Output	24v AC 2A
Size	L200mm W120mm H110mm (without spring holder)
Weight	1,8Kg
